Damping Hinge MH200-4004
Price range: 6,89 € through 9,89 €
Constant Torque Hinge Position Control,,Resistance Hinge,Zinc Alloy Hinge,Size:38*40mm and 57.1*50.8mm available,with different standard Torque 1.4/1.8/2.3/3.4N.m.Technical requirements:After 20,000 times lifespan,the torque attenuation deviation is ± 20%Constant Torque Hinge Position Control,Friction Hinge,Resistance Hinge,Zinc Alloy Hinge,Size:38*40mm and 57.1*50.8mm available,with different standard Torque 1.4/1.8/2.3/3.4N.m.Technical requirements:After 20,000 times lifespan,the torque attenuation deviation is ± 20%
- Compliance Standard: REACH No.1907/2006
- Configuration: Tool Locking
- Corrosion Resistance: Up to 720h Neutral Salt Spray
- Material: Stainless Steel / Zinc Alloy
压缩闭合主要用于门、翻盖、盖子和外壳，这些门、翻盖和外壳需要更高的密封接触力才能在压力下关闭组件。
它们的杠杆作用会产生挤压密封件的夹紧力。因此，它们对振动、灰尘和/或水有很高的抵抗力。
外壳锌压铸。
支架、螺丝和螺母钢。
外壳黑色，粉末涂层。
支架、螺丝和螺母镀锌。
可调节距离H1可选择从2毫米到19毫米或24毫米到42毫米。
门叶厚度最大为5毫米。
表格A：不可锁定
表格B：可上锁
闭合是相同的，即每个锁都可以用相同的钥匙打开。
按下按钮，将闭合带入打开位置，门就可以打开。
通过关闭杠杆，门被压在框架上。
-机械工程
-控制柜
- 车辆建造
-实验室设备
-包装行业
1.根据草图制作装配部分。
2.从正面将盖插入安装开口。
3.從背面擰緊螺絲，從而將安裝支架拉到門板上，並將封口固定在安裝開口中。
包括螺丝、螺母和安装支架。
可上锁的压缩杆锁每把都配有2把钥匙。
1）装配部分
Additional information
| Size | 38*40mm, 50*58mm |
|---|---|
| Surface | black, natural, Stainless steel |
| Torque(N.m) | 1.4/ N.m, 1.8/ N.m |
Frequently Asked Questions
Consider the door or panel dimensions, weight, opening angle, mounting method, required service life, and operating environment. Load direction and installation position should also be confirmed before selecting a hinge.
A torque or positioning hinge is suitable when a lid, display, or access panel needs to remain at a selected angle without an additional stay. The required torque should be matched to the panel weight and geometry.
